Motherboard repairing

Rt809h universal programmer english software download

by

Rt809h universal programmer english software download

We are going to see Rt809h universal programmer english software download from our webssite for free. Rt809f universal programmer driver, we had checked it on Windows 10. The driver is running smoothly. If you install the software, there is no need to install a separate driver for the Rt809f universal programmer. Rt809h can be available on olx but on olx, you can get not a great quality machine.

It can happen that the wire of the Rt809h programmer adapter may be broken or not working adapter. So it is advisable to look carefully or fully avoid websites like OLX, eBay, etc for new ones. As Rt809h universal programmer comes with an also lesser price that we can afford. This toolkit very helpful in programming bios which are very helpful in laptop repairing cases – no display for laptop, no display for desktop, sometimes controllers like keyboard, mouse, pch, sio not working.

RT809f is one of the famous programmers for laptop bios programming in laptop repairing.

It is also used in desktop motherboard repair for formatting bios. You can pruchase this programmer from amazon.com at Indian rupees  ₹18,530. There is also low price bios programmer which is rt809f bios programmer which is basic usage. The specifications for the Rt809h bios programmer are as follows.

rt809f programmer latest version
rt809f programmer latest version
Model Name‎Rt809h
Screen Size7 Inches
RAM Memory Installed Size64 GB
Compatible DevicesPersonal Computer, Laptop
ManufacturerDHRUV-PRO
Display Type‎LCD
CPU ManufacturerVia

Programmer purchase link for rt809h universal programmer

the Rt809h universal bios programmer is available for purchase. You can buy it from amazon.com rt809h programmer and use it. It comes with Bios different many more holdings for almost any type of bios chip programming.

Also with rt809h there comes a wire to connect to a computer. All parts come with from the company.

How to install Rt809h programmer toolkit software

You have to install the rt809f toolkit software on your computer. from below

Rt809h Universal Programmer Free English Version Software Download

You can download the bios files for free of cost. Find them according to your laptop motherboard model.

After the successful write operation, you can close the software and remove the bios. Then insert it into the laptop motherboard and the problem must be fixed.

thank you!

RT809F Programmer Software download

by

screen for rt809f programmer toolkit installation and connect to bios. all images sources @ alisaler.com

Rt809f is a free software toolchain in the English language download. Rt809f driver, we have checked it on Windows 10. The driver is running smoothly. If you install the software, there is no need to install a separate driver for the Rt809f programmer. rt809f can be available on olx but on olx, you can get not a great quality machine. You will get here rt809f programmer software download for free of cost. We will provide you below RT809F Programmer Software completely free download.

It can happen that the wire of the rt809f programmer adapter may be broken or not working adapter. So it is advisable to look carefully or fully avoid websites like olx, eBay, etc for new one. As rt809f programmer comes with an also lesser price that we can afford. This toolkit very helpful in programming bios which are very helpful in laptop repairing cases – no display for laptop, no display for desktop, sometimes controllers like keyboard, mouse, pch, sio not working.

RT809f is one of the famous programmers for laptop bios programming in laptop repairing.

It is also used in desktop motherboard repair for formatting bios. The bios comes at 6,350 Indian Ruppes at Amazon.com. There is also universal bios programmer comes with price around indian ruppes 18500 as Rt809h universal bios programmer for advance editing. The specification for rt809f bios programmer are as follows.

Model Name‎RT809F
Ram Memory Technology‎DDR2, DDR3
Hardware InterfaceInternal Solutions Port
Compatible DevicesPersonal Computer, Laptop
ManufacturerDHRUV-PRO
Country of Origin‎China
Item WeightItem Weight

Programmer purchase link

the Rt809f bios programmer is avaiulable for purchase. You can buy it and use it. It comes with Bios chip 2 holders , small board for different type of bios holding and Rt809f programmer adapter and wire to onnect to computer. First setup by removing the Bios which have to programmed from laptop or desktop and put it on the adapter for bios provided with rt809f with box.

Then You have to connect the wire which comes with the programmer to the computer or desktop and the start the software.

Then try to connect until the ‘connection is successful’ message will come. Then click on the smart identity button as per below.

A screenshot of a computer Description automatically generated

Then you can use Save button to save first the existing file as a backup file if something bad happens. Save it to any location in computer.

Secondly, click on the Write button to write the BIOS file into the BIOS programmer.

A screenshot of a computer Description automatically generated

you can download the bios files for free of cost. Find them according to your laptop motherboard model.

How to install rt809f programmer toolkit software

You have to install the rt809f toolkit software on your computer. from below

RT809F Latest Working Free Version Software Download link

After the successful write operation you can close the software and remove the bios. Then insert it into the laptop motherboard and the problem must be fixed.

thank you!

Premium Accounts Reality

by

no one is going to give you premium account for free. There will be virus or trojon link in the software or website. Best way to get it from some trusted provides like we are. Another way is to get get it from free program offer by them to get some validity access for some vaild users.

Thank you!.

Free schematics bios boardviews

by

Schematics Bios Boardviews for all latest and old laptops and desktops.

Free schematics bios boardviews
Free schematics bios boardviews

Which brand’s schematics are available

We offer brands like Hp Dell Lenovo Samsung Apple Asus Acer Sony Msi Avita Hcl Toshiba laptops and desktop schematics bios and boardview free of cost from the below button. you can use the motherboard code to search for download free schematics bios board views by clicking the below button.

Download Free Schematics Bios Boardview

Thank you for your visit.

Quanta Motherboard SIO Requirements

by

SIO Requirements Supplies in Quanta Motherboards are given below –

Quanta motherboard sio io signals list

1. VCC

This 3v wake up supply on any one VCC pin.

2. AVCC

This is Analog VCC Supply Signal . It is important signal without which analog circuit don’t work in I/O.

3. GND, AGND

It is ground beep signal. Also it have analog ground signal which gives ‘beep’ on the multimeter.

4. 3920_RST#

In Quanta motherboard EC_RST digital signal signal motly given by this name.

5. ACIN

It is similar and same as ACOK signal in Quanta motherboard. This signal get’s generated in Charging IC and then it come to SIO in form of ACIN signal.

6. LID_EC#

This is name for Lid Switch signal in Quanta motherboard.

7. Signal Miss Sometimes in Quanta Motherboard

There is Thermal Signal is missing in Quanta Motherboard. SIO I/O works with very small components to inform CPU.

8. BIOS_RD#, BIOS_WR#, BIOS_CS#

This signals are connected with BIOS. The connectivity is responsible for enabling sometimes step down enable.

9. S5_ON

In Quanta motherboard S5_ON signal is the step down IC’s Enable signal name.

10. NBSWON1#

This power button siganl in Quanta motherboard . It stans for NoteBoomSwitchOn signal. It comes 3V before power button press, 0V when power button pressed and 3V after released the power button. Here the High-Low-High concept for power sequence is created.

11. RSMRST#

This is the first output signal generated by I/O.

12. DNBSWON#1

This is the power button out signal in Quanta motehrboard. It stands for DelayNorthBoardSwitchON.

13. Signal Miss Sometimes in Quanta Motherboard

Sometimes Lid Switchout Signal is Missing in Quanta motehrboard’s SIO I/O.

14. SUSB#, SUSC#

WHen SIO I/O gives RSMRST and PWRBRNOUT signas to PCH, The PCH gives 2 to 3 signals to I/O. These signals are PM_SLP_S3, PM_SLP_S4. In perticulary in Quanta motherboard they named as SUSB# and SUSC#.

SUSB# signal = SLP_S3# signal and SUSC# signal = SLP_S4# signal.

These are the basic requirements for no power on condition in computer and laptop. If these signals come then we can say that our computer or laptop is turn on.

If the laptop is not starting even if these signals coming then we can say that our desktop or laptop motherboard is gone into no display case similar to desktop.

Conclusion

In this we have explained what signal names you should get in Quanta motherboard’s SIO. If you see in the Compal SIO I/I signals, you will have different signals.

We also have basic requirement for general SIO I/O where you get to see the basic requirement for SIO I/O. If not seen please visit and get knowledge expanded.

Above demo is for quanta SIO name quanta_r33_r1a.

You can use the page numbers to go directly to a page where the diagram is. Beware there can be a difference of 1-2 pages in sequence in the diagram we see.

Thank You!

Wistron Motherboard Nuvoton SIO Basic Requirement

by

We are going to see Nuvoton SIO’s Basic Requirement in Wistron Motherboard. Wistron motherboard mostly uses Nuvoton SIO IO.

SIO Supply –

Wistron motherboard Nuvoton SIO IO signals names:

  1. VCC
  2. AVCC
  3. VDD
  4. EXT_RST#
  5. PSL_IN1#, PSL_IN2#
  6. LID_CLOSE#
  7. VD_IN1,VD_OUT1#
  8. PSL_IN2#
  9. RSMRST#_KBC
  10. PM_PWRBTN#
  11. PM_SLP_S3#, PM_SLP_S4#

We are going to see them one by one with a description

1. VCC

This is wake up signal for SIO. We see 3v on any 1 pin which is written VCC.

2. AVCC

This is 3v Analog VCC Supply.

3. VDD

This 3v signal comes after the laptop power button presses.

4. EXT_RST#

This is EC_RST# signal for the Wistron motherboard having Nuvoton SIO IO. This gives a 3.3v signal.

5. PSL_IN1#, PSL_IN2#

AC_OK# signal comes here with 0b. If it is written like AC_OK without hash then 3v signal comes. Likewise, if AC_IN# comes then 0v, if SC_IN is without hash then 3v. Power_button signal also comes within PSL_IN1# and PSL_IN2#.

6. VD_IN1, VD_OUT1#

These are thermal signals for SIO in Nuvotone SIO.

7. PSL_IN2#

This signal is the power_button signal. It comes with 3v as default when the power button is pressed it comes 0v when the power button releases it comes 0v.

8. RSMRST#_KBC

It is the RSMReset signal in the Wistron motherboard. This 3v signal goes to PCH.

9. PM_PWRBTN#

PM stands for Power Management. It is PCH’s power management. It is a power button output signal in the Wistron motherboard Nuvoton sio io.

10. Signal Missed

Here Lid Switch signal is missing sometime in Winstron motherboards Nuvotone sio io ic. DY means ‘dead end’ in schematics and there is no further component is present.

11. PM_SLP_S3#, PM_SLP_S4#

This signal comes from PCH to Programmable or Non Programmable SIO IO Chip. PM means Power management here.

Thank you.
